U009 48V 20Ah Samsung5000 LG5000 Cells EBike Battery For Rad Power Bike For 350W 500W 750W 1000W 1200W 1500W 1800W Motor【USA Stock】/3-7days arrive
| Battery Parameter |
| Battery Model |
UnitPackPower-U009 |
| Battery Type |
Li ion Battery |
| Rated Voltage |
48V |
48V |
| Rated Capacity |
20AH |
20AH |
| Watt Hour |
960WH |
960WH |
| Battery Cell |
21700 LG52VT/50L |
21700 Samsung50E |
| Series&Parallel |
13S4P |
13S4P |
| Fit Motor Power |
0-1800W |
0-1800W |
| Battery Weight |
4.74KG |
4.74KG |
| IP Rating |
IP65 |
IP65 |
| Max. Constant Discharge Current |
50A |
50A |
| Peak Current |
150A |
150A |
| Max.Charge Current |
3A |
3A |
| Max.Charge Voltage |
54.6V |
54.6V |
| Discharge Cut-off Voltage |
36.4V |
36.4V |
| Cycles Life |
≥1000 |
≥1000 |
| Charger |
54.6V 3A |
54.6V 3A |
| Discharge Connector |
XT60 |
XT60 |
| Dimension |
385*97*120mm |
385*97*120mm |
| Charger Temperature |
0~45℃ |
0~45℃ |
| Discharge Temperature |
-10℃~60℃ |
-10℃~60℃ |
| BMS |
Overcharge, overdischarge and over-temperature protection |
Note:The battery base is locked to the bottom of the battery upon arrival. Use your key to unlock and detach the base before installation.
Package list:
Ebike battery pack*1
Charger*1
Keys*2
User Manual*1
How to choose the battery Specifications that best suits you?
1.The voltage of the battery keep the same as the voltage of the motor.
2.The maximum power and maximum current (BMS) of the battery must be greater than or equal to the power and current of the motor and controller.
3.Please confirm that the battery size is compatible with your e-bike's installation space before place an order.
4.Make sure that the battery is charged at least every 3 months to switch to the highest performance and lifetime.
The U009 battery has the same install base as rad power battery, It can be as a rad power battery replacement. But please double check the dimensions of the U009 battery. And it's a down tube battery style, Suitable for most electric bicycle frames on the market.
The U009 battey is our private model of ebike battery, Response to the needs of some customers, The U009 batteries have a 30-50A fuse build in the battery, And also have a 30A-50A BMS build in the battery, double protection to make the battery more safetly.
The lock and key of the U009 battery have two functions, Power on/off switch+ safe lock function.If need turn on the battery, Please turn on the key. If want to fully charged, Please turn on the key.
Charger Plugs and Discharge Connectors Optional
1. Charger Plug:US EU UK AU plugs optional, will provide according to delivery country if without requested.
2. Discharge Connector: There are 8 kinds optional as below picture, will soldered with default female connector&extra male connector if without requested.
3. If you have any requirement about this, please leave message in your order.
We provide 1 year warranty for all electric bike batteries.
Any battery with quality problem in one month we can return the money after you provid the proof.
After one month we can send BMS or cells to you for repair,or you can send it back to repair as well.
All our electric bicycle batteries with high quality cells and BMS, and they will be 100% tested before shipping.
Our global after-sales service centers are located in Westhausen Germany, California USA, Victoria AU.
If your battery cant work during warranty, sent it to nearest after-sales center, we will repair it well then send it to you.
Trade & Market
| Main Markets |
Total Revenue(%) |
| North America |
23.00% |
| Western Europe |
20.00% |
| Oceania |
15.00% |
| Northern Europe |
12.00% |
| Eastern Europe |
9.00% |
| Southern Europe |
8.00% |
| Southeast Asia |
6.00% |
| South America |
5.00% |
| Mid East |
2.00% |
- Do not immerse the battery in water or seawater, keep the battery stands by in a cool dry surrounding.
- Does not use or leave the battery near a heat source as fire or heater.
- Use the battery charger specifically for that purpose when recharging.
- Do not upside down the position and negative terminals.
- Do not connect the battery electrodes to an electrical outlet.
- Do not discard the battery in fire or a heater.
- Do not short-circuit the battery by directly connecting the positive and negative terminals with metal objects.
- Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.
- Do not strike, trample or throw the battery.
- Do not directly solder the battery and pierce the battery with a nail or other sharp objects.
Shenzhen Unitpackpower Technology Co., Ltd
We are a professional manufacture with factory, which produce all kinds of high quality lithium baterruies as customers' requirements and designs. Our products have already exported to many places all over the world. This is a team which not only master advanced science and technology but also full of passion and energy. We are trying best to provide you high quality products as well as the sincere services.
Why Choose UPP (Unit Pack Power)?
1) Factory Direct Store: We assemble all batteries in our own factory, never use fake or cheap cell pack sell at lowest price to attract buyers. In addtion, we have to scrimp on everything, assemble them as quickly/cheaply as possible. We don’t take chances when it comes to our batteries or your safety!
2) Official High Quality Cell Sources: We only source genuine A-grade genuine cells from the official sources.
3) Every Battery Made Cycle Test: Each pack is ran through a full charge and discharge before leaving our facility to make sure you are getting every amp hour you paid for.
The test include: Short Circuit Safety Test √ Overcharge Safety Test √ Crush Safety Test √ Needing Safety Test √ Extrusion Safety Test √
4) Best Oversea After-sale Service: We do all this and offer it at our usual low pricing, we don’t charge a premium for Safety and Reliability. We have a proven track record of offering great after-sales support and warranty repairs/replacements. We will not leave you stuck (12 Month warranty, with Support Centres in Germany&Belgium&USA&Canada&Australia).
FAQ
Q: What type of this electric bike battery?
A: It is li ion battery, Chemical is Li(NiCoMn)O2.
Q: What is the difference between li ion battery, NI-MH battery and Lead acid battery?
A: E-bike Li-ion battery have longer cycle life, normal cycle life is 800-1000 times, and also with light weight, small size, No memory effect, Nontoxic, environmental friendly.
Q: What's temperature range of charge and discharge?
A: Charge Temperature: 0 to 45°C and Discharge Temperature: -20 to 65°C
Q: What kind of cells used on this electric bicycle battery?
A: Different capacity with different cells, we make the battery with original A grade Samsung,Panasonic,Sanyo,LG and high quality domestic cells,all can be customized as your requests.
Q: Do your e-bike battery come with charger?
A: All of our e-bike batteries come with charger, Unless it says no charger. We have normal charger and fast charger. If you need fast charger please contact with us.
Q: Do your electric bike batteries come with BMS?
A: Yes, Our batteries all with SEIKO IC BMS, with stable performance.Which can protect the battery avoid short circuit,Overcharged,Over discharge and Over current.
Q: Can you provide OEM and ODM service?
A: Yes, We are a professional Electric Bike Battery manufacture with factory, which produce all kind of high quality E-bike lithium batteries as customers' requirements and designs, welcome to place OEM and ODM orders and visit our factory.
